Available Finishes
Standard Veneers – Cherry, Walnut, Oak & Black Ash.
Standard Paints – Satin Black, Satin White
Premium Veneers (up-charge applies) – Rosewood, European Crown Cut Walnut, Pippy Oak, Burr Magnolia, Burr Poplar.
High Gloss (up-charge applies) – Clear High Glossed Veneer, Piano Black, Piano White
Active
Drivers: HF 1″/25mm Dual-Suspension S-Spec, Mid 3″/75mm Super Dome, LF 2 x 12″314mm SL
Amplitude Linearity (±2dB): 60Hz-12kHz
Cut-off Frequencies (-6dB, free-standing): 32Hz, 20Khz
Horizontal Dispersion: ±80°, Coherent
Vertical Dispersion: ±10°, Coherent
Max. Continuous SPL (1 metre): 118dB
Crossover Frequencies: 380Hz, 3.5kHz
Input Connector: Female XLR
Input Sensitivity: 2V
Input Impedance: Balanced > 10kΩ
Amplifier Output: Bass 275+275W, Mid 200W, High 100W
Filters: 4th Order Active Critically Damped
Overload Protection: Active FET momentary gain reduction plus thermal tweeter protection
Dimensions (HxWxD): 1586 x 398 x 535mm / 62.44 x 15.67 x 21.06″
Passive
Drivers: HF 1″/25mm Dual-Suspension S-Spec, Mid 3″/75mm Super Dome, LF 2 x 12″314mm SL
Amplitude Linearity (±2dB): 60Hz-12kHz
Cut-off Frequencies (-6dB, free-standing): 32Hz, 20Khz
Horizontal Dispersion: ±80°, Coherent
Vertical Dispersion: ±10°, Coherent
Max. Continuous SPL (1 metre): 117dB
Crossover Frequencies: 380Hz, 3.5kHz
Input Connector: Tri-Wire Binding Posts
Sensitvity: 91db/W@1m
Impedance: 8Ω Nominal
Filters: 2th Order Passive Critically Damped
